5-104893-2 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE AMPMODU 50/50 Grid 5-104893-2, 20 Pos IDC Receptacle

MPN5-104893-2
Active

TE AMPMODU 50/50 Grid receptacle, 5-104893-2, 20 positions, 0.050" (1.27mm) pitch, 2 rows, IDC termination for 28 AWG ribbon cable, gold 30.0µin contacts, black housing, closed end, free hanging.

$7.7100Ref. price · indicative, final on quote
5-104893-2 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

5-104893-2 Technical Specifications
ParameterValue
SeriesAMPMODU 50/50 Grid
Wire typeRibbon Cable
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Wire gauge28 AWG
Cable terminationIDC
ColorBlack
Pitch0.050\" (1.27mm)
PackageTube
FeaturesClosed End
Row spacing0.050\" (1.27mm)
Contact finishGold
Rows2
Positions20
Contact finish thickness30.0µin (0.76µm)

Product details

The TE 5-104893-2 is a 20-position, dual-row receptacle in the AMPMODU 50/50 Grid series. It terminates 28 AWG ribbon cable via an IDC (insulation displacement) slot — no wire stripping, just a one-shot press. The 0.050" (1.27mm) pitch on both rows and between rows matches standard 1.27mm rainbow ribbon cable, so it lands on the same footprint as any 50/50 Grid header. Black housing, closed end (no pass-through), free-hanging mount.

Fit Check — Pitch, Positions, and Cable

Pitch is 0.050" (1.27mm) on both the contact row and the row-to-row spacing — that is the defining dimension of the 50/50 Grid family. The 20 positions (2 rows of 10) match any 20-pin dual-row 0.050" header. A 30 AWG ribbon will not get a reliable gas-tight joint; a 26 AWG is too thick for the slot.

Frequently asked questions

Where can I buy 5-104893-2?

5-104893-2 is sourced through independent distribution and quoted to order against an RFQ. Availability and current pricing are confirmed at quote time — no stock-holding claim is made here.

What wire gauge does 5-104893-2 support?

It supports 28 AWG ribbon cable only. The IDC termination is sized for that gauge; 30 AWG or 26 AWG will not produce a reliable connection.

Is 5-104893-2 RoHS compliant?

Yes, it is ROHS3 Compliant.

What is the pitch of 5-104893-2?

The pitch is 0.050" (1.27mm) on both the contact row and the row spacing, matching standard 1.27mm ribbon cable.
