5-104893-5 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE AMPMODU 50/50 Grid 5-104893-5, 50 Pos IDC Receptacle

MPN5-104893-5
Active

TE Connectivity AMPMODU 50/50 Grid receptacle, 5-104893-5, 50 positions, 2 rows, 0.050" (1.27mm) pitch, IDC termination for 28 AWG ribbon cable, gold 30.0µin plating, free hanging, black housing, closed end.

$12.4200Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

5-104893-5 Technical Specifications
ParameterValue
SeriesAMPMODU 50/50 Grid
Wire typeRibbon Cable
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Wire gauge28 AWG
Cable terminationIDC
ColorBlack
Pitch0.050\" (1.27mm)
PackageTube
FeaturesClosed End
Row spacing0.050\" (1.27mm)
Contact finishGold
Rows2
Positions50
Contact finish thickness30.0µin (0.76µm)

Product details

50-Position IDC Receptacle for 28 AWG Ribbon Cable

The TE Connectivity 5-104893-5 is a 50-position receptacle in the AMPMODU 50/50 Grid series, designed for mass-termination to 28 AWG ribbon cable via IDC contacts. The closed-end housing prevents stubbing during cable insertion and keeps the contacts aligned.

IDC termination is a one-step press operation — the ribbon cable is laid across the open contacts and the cover is pressed down, slicing through the insulation to make contact with each conductor. The 28 AWG wire gauge is fixed; the connector is not compatible with other gauges. The black housing is a single piece with a closed end, so the cable stops at a defined depth.

This receptacle mates with the matching AMPMODU 50/50 Grid header — a 50-position, 0.050" pitch, dual-row pin header. The gold-to-gold contact interface is rated for the same 30.0µin plating on the header side, giving a consistent mating cycle life.

Frequently asked questions

What is the pitch of 5-104893-5?

The pitch is 0.050" (1.27mm) on both the row-to-row and contact-to-contact spacing, matching standard 0.050" ribbon cable.

What connector mates with 5-104893-5?

It mates with a 50-position, 0.050" pitch, dual-row AMPMODU 50/50 Grid pin header (male pins).
