TE Connectivity AMP Connectors 5-487508-7 — FFC / FPC Cable Assemblies

5-487508-7 TE Connectivity Triomate FFC Connector 8

MPN5-487508-7
Active

TE Connectivity AMP Connectors Triomate series FFC/FPC connector, 5-487508-7, 8 positions, 0.100" (2.54mm) pitch, right-angle through-hole, top contact, tin-plated phosphor bronze contacts, 1A, 250V, UL94 V-0, tray.

$0.9400Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 5-487508-7 datasheet (PDF)
RoHSROHS3 Compliant
SeriesTriomate
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5-487508-7 key specifications
ParameterValue
SeriesTriomate
MountingThrough Hole, Right Angle
Flat flex typeFFC, FPC
Connector (Contact type)Contacts, Top
Voltage rating250V
Current rating1A
Operating temperature-55°C ~ 105°C
Housing colorBlack
Contact materialPhosphor Bronze
Housing materialPolyester Thermoplastic, Glass Filled
Height above board0.190\" (4.83mm)
Material flammability ratingUL94 V-0

All specifications

5-487508-7 additional specifications
ParameterValue
Pitch0.100\" (2.54mm)
PackageTray
TerminationKinked Pin
Mating cycles25
Contact finishTin
FFC, FCB thickness0.13mm ~ 0.38mm
Positions8
Contact finish thickness196.9µin (5.00µm)

Product details

8-position 2.54mm pitch FFC connector for board-edge signal routing

The 5-487508-7 is an 8-position FFC/FPC connector from the TE Triomate series, on a 0.100" (2.54mm) pitch — a legacy spacing that still sees use in low-density signal interfaces where fine-pitch connectors are not required.

Tin contacts and 25 mating cycles — occasional-service duty

The tin-plated phosphor bronze contacts (5.00µm thickness) are rated for 25 mating cycles — fine for a one-time assembly or periodic maintenance, but not for frequent disconnect applications where gold plating would be needed.

Frequently asked questions

What is the pitch of the 5-487508-7 FFC connector?

The 5-487508-7 has a 0.100" (2.54mm) pitch, which is a standard through-hole spacing compatible with many legacy FFC cable assemblies and PCB layouts.
