TE Connectivity AMP Connectors modular plug, order code 5-557965-2, 6p4c (RJ11, RJ14), Cat3, unshielded, IDC termination, gold-plated phosphor bronze contacts, 26-28 AWG solid flat oval cable, translucent clear polycarbonate housing.
| Parameter | Value |
|---|---|
| Cable type | Flat Oval Cable, Solid Wires |
| Connector type | Plug |
| Wire gauge | 26-28 AWG |
| Color | Translucent - Clear |
| Contact material | Phosphor Bronze |
| Housing material | Polycarbonate (PC) |
| Length | 0.530\" (13.46mm) |
| Package | Bag |
| Ratings | Cat3 |
| Shielding | Unshielded |
| Termination | IDC |
| Contact finish | Gold |
| Contact finish thickness | 50.0µin (1.27µm) |
| Number of positions (Contacts) | 6p4c (RJ11, RJ14) |
The 5-557965-2 is a 6p4c (RJ11, RJ14) modular plug from TE Connectivity AMP Connectors, terminated via IDC to 26-28 AWG solid wire flat oval cable. Contacts are gold-plated phosphor bronze with 50.0µin (1.27µm) plating; the translucent clear polycarbonate housing allows visual inspection of the wire insertion.
Available through independent surplus channels; quantities are lot-specific and confirmed at RFQ.
