TE Connectivity CHAMP.050 I series, Board to Board High Density Receptacle, 40 Positions, 2 Rows, Through Hole Solder, Gold 8.00µin Contact Finish, Board Lock
| Parameter | Value |
|---|---|
| Type | Board to Board, High Density |
| Series | CHAMP .050 I |
| Mounting | Through Hole |
| Connector type | Outer Shroud Contacts |
| Package | Tray |
| Features | Board Lock |
| Termination | Solder |
| Contact finish | Gold |
| Rows | 2 |
| Positions | 40 |
| Contact finish thickness | 8.00µin (0.203µm) |
This is a practical advantage in high-density layouts where the connector sits close to other components — the lock prevents the part from shifting during wave solder and reduces the risk of lifted pads from cable strain.
Submit an RFQ for the quantity and delivery timeline you need.
The 5175475-5 is a 40-position receptacle arranged in two rows, with outer shroud contacts. It is a board-to-board high-density connector with through-hole solder termination and a board lock feature.
