25-Position DB-25 D-Sub Plug, Solder Termination
The 25 circuits and 2-row layout match the standard DB-25 footprint, making this the plug half of a common serial or parallel interface pair. Gold flash plating on the brass contacts handles signal-level current at 6A per contact with a 125V voltage rating, while the steel shell with yellow chromate zinc finish provides EMI shielding and mates with the standard DB-25 receptacle.
6A Per Contact, Gold Flash — Signal Duty, Not Power
Rated 6A per contact at 125V, this plug is built for signal and low-power interconnect, not bus-level current. The gold flash contact finish (thin gold over nickel) is standard for D-Sub signal contacts — it provides corrosion resistance and reliable contact over several hundred mating cycles, but the thin plating means it's not intended for high-cycle or high-wear applications. The 6A rating is per contact with all positions loaded, so derating applies if the ambient temperature approaches the 105°C upper limit. For a 25-position cable assembly carrying multiple signals, the aggregate current through the shell ground path should be considered.
RoHS compliance is confirmed on the listing.
