TE AMPLIMITE HD-20 5207828-4, D-Sub Receptacle 25-Pos

MPN5207828-4
Active

TE Connectivity AMPLIMITE HD-20 D-Sub receptacle, 5207828-4, 25 positions, 2 rows, vertical through-hole, solder termination, gold-plated phosphor bronze contacts, 6 A, 125 V, black polyester shell.

$9.3400Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 5207828-4 datasheet (PDF)
RoHSRoHS Compliant
SeriesAMPLIMITE HD-20
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5207828-4 key specifications
ParameterValue
SeriesAMPLIMITE HD-20
TypeSignal
MountingThrough Hole
Connector typeReceptacle, Female Sockets
Voltage rating125V
Current rating6A
Shell size, connector layout3 (DB, B)
Operating temperature-55°C ~ 105°C
ColorBlack
Contact materialPhosphor Bronze
Dielectric materialPolyester
Material flammability ratingUL94 V-0

All specifications

5207828-4 additional specifications
ParameterValue
PackageTube
TerminationSolder
Contact finishGold
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions25
Contact finish thickness30.0µin (0.76µm)

Product details

Standard DB-25 Female for Panel and PCB Mount

The TE Connectivity AMPLIMITE HD-20 5207828-4 is a standard-density D-Sub receptacle with 25 positions arranged in 2 rows — the classic DB-25 layout. It mates with any standard DB-25 male plug (solder cup or PCB mount) that uses the same shell size 3 (DB, B) footprint. This is a vertical through-hole version with solder termination, intended for permanent PCB mounting. The unthreaded housing/shell flange means it relies on the mating plug's hardware (or a separate bracket) for panel retention — not a self-locking design.

It is RoHS compliant.
