Blade Power Receptacle for Backplane Distribution
It accepts female blade sockets in a single-row layout, with all four positions loaded as power contacts — no signal pins mixed in. Rated 250V with a UL94 V-0 housing, it suits power distribution in telecom, server, and industrial chassis where the backplane routes the main DC or AC rail.
Press-Fit Assembly and Temperature Range
Press-fit termination is the key assembly feature here — the compliant pin compresses as it enters the plated hole, creating a gas-tight joint without heat. That makes it field-reworkable and avoids thermal stress on the backplane.
Contact Plating and Mating
Contacts are finished in gold or gold-palladium on the mating interface — the dual-spec plating means the actual finish depends on the production batch, but both grades provide corrosion resistance for the repeated mating cycles a backplane module sees during field service. No pitch figure is published in the standard listing, so confirm the board footprint against the product drawing before committing the layout.
