5223995-3 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE 5223995-3 UPM Receptacle, 6-Position Blade Power

MPN5223995-3
Active

TE Connectivity UPM (Universal Power Modules) receptacle, female blade sockets, 6 positions, 1 row, press-fit through-hole, 250 V, UL94 V-0, gray.

$11.7300Ref. price · indicative, final on quote
5223995-3 datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

5223995-3 Technical Specifications
ParameterValue
SeriesUPM (Universal Power Modules)
Mounting typeThrough Hole
Connector typeReceptacle, Female Blade Sockets
Voltage rating250V
Connector usageBackplane
Operating temperature-55°C ~ 125°C
ColorGray
Material flammability ratingUL94 V-0
PackageTube
TerminationPress-Fit
Contact finishGold or Gold-Palladium
Rows1
Positions6
Contact layout, typical6 Power

Product details

All six positions are loaded as power contacts — there are no signal pins in this layout.

Press-Fit Termination — No Solder, Specific PCB Prep

The board layout needs the correct finished hole diameter and a controlled insertion force; the press-fit joint is gas-tight and rework-friendly if a pin is damaged during assembly.

Mating Half and Contact Plating

Voltage and Compliance

Rated 250 V, which covers intermediate DC bus voltages common in backplane power distribution. RoHS compliant per current directive.

Frequently asked questions

Does the 5223995-3 have a mating connector?

Yes, it mates with the UPM header, male blades — the 5223968-1 is a 3-position example of that mating half. Both are press-fit, through-hole, and share the same contact finish and voltage rating.

Is 5223995-3 a press fit connector?

Yes, the 5223995-3 uses press-fit through-hole termination. The compliant pin is pressed into a plated through-hole — no solder required.
