PIDG spade terminal, 10-12 AWG, #10 stud
The 52432-1 is a PIDG-series spring-snap spade terminal for 10-12 AWG wire with a #10 stud size, insulated in yellow nylon and terminated by a serrated crimp. The tin-plated phosphor bronze contact and serrated termination grip the conductor, while the insulation sleeve covers the crimp barrel over a wire diameter range of 0.150" to 0.250" (3.81 mm to 6.35 mm).
Stud size selection across the PIDG series
The 52432-1 (#10 stud) sits between the 52431-1 (#8 stud) and the 52433-1 (1/4" stud) — all three share the same 10-12 AWG wire range, serrated crimp, and tin-plated phosphor bronze contact; the stud size determines the mating ring terminal or bus bar hole.
