TE Connectivity AMP Connectors 5353928-1 — USB / HDMI Cable Assemblies

TE Connectivity 5353928-1 USB Type-A Receptacle, Panel Mount

MPN5353928-1
Active

TE Connectivity 5353928-1 USB 2.0 Type-A receptacle, 4 contacts, panel mount with right-angle SMT termination, gold-plated contacts, UL94 V-0, black insulation.

$7.1386Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5353928-1 specifications
ParameterValue
MountingPanel Mount, Surface Mount, Right Angle
Connector typeUSB-A (USB TYPE-A)
Positions4
Mounting featureFlange, Vertical
Insulation colorBlack
Shell (Shielding material)Copper Alloy
Material flammability ratingUL94 V-0
GenderReceptacle
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesBoard Guide
TerminationSolder
Contact finishGold
SpecificationsUSB 2.0
Number of ports1

Product details

The panel-mount USB jack that doesn't float on the solder joints

Mounting that splits the mechanical and electrical paths

The panel-mount flange carries the mechanical retention — the connector is screwed to the panel face, not held by the solder fillets. The right-angle SMT tails then only carry the signal and power, not the shear from a USB cable yanked sideways. This is the right part when the USB port needs to survive repeated customer plugging without cracking the solder joints on the board.

No last-time-buy or NRND notice is recorded.

Frequently asked questions

Is 5353928-1 RoHS compliant?

Yes, the 5353928-1 is ROHS3 compliant per the manufacturer's listing.

What is the mounting type for 5353928-1?

The 5353928-1 uses a hybrid mount: panel mount via the flange, with right-angle SMT tails soldered to the PCB. The flange takes the mechanical load; the SMT tails handle the electrical connection.
