TE Connectivity AMP Connectors 5555077-1 — Modular Jacks (RJ)

TE Connectivity 5555077-1 RJ45 Jack, 6P6C R/A SMT, Gold

MPN5555077-1
Active

TE Connectivity modular jack, 5555077-1, 6P6C (RJ11/RJ12/RJ14/RJ25), right-angle SMT, unshielded, gold 50.0µin contacts, tray.

$3.9900Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 5555077-1 datasheet (PDF)
RoHSRoHS Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5555077-1 specifications
ParameterValue
MountingSurface Mount
Connector typeJack
Operating temperature-40°C ~ 85°C
LED colorDoes Not Contain LED
Contact materialPhosphor Bronze
Housing materialPolyamide (PA), Nylon
PackageTray
RatingsCat3
FeaturesBoard Lock, Panel Stops, Solder Retention
ShieldingUnshielded
Orientation90° Angle (Right)
TerminationSolder
Tab directionDown
Contact finishGold
Rows1
Number of ports1
Contact finish thickness50.0µin (1.27µm)
Number of positions (Contacts)6p6c (RJ11, RJ12, RJ14, RJ25)

Product details

The TE Connectivity 5555077-1 is a 6p6c modular jack — the 6-position, 6-contact variant that accepts RJ11, RJ12, RJ14, and RJ25 plugs. It is unshielded, right-angle (90°) for edge-board mounting, and terminates via surface-mount solder tails.

Mechanical Retention and Board Fit

Three features lock this jack to the PCB: a board lock for SMT reflow retention, panel stops to set the correct height above the board, and solder retention pads that anchor the body against cable insertion and extraction forces.

Frequently asked questions

Where can I buy 5555077-1 and how do I get a price?

Submit a request for your target quantity to receive current pricing and lead time — availability is confirmed at quote time.

Is 5555077-1 shielded or unshielded?

Unshielded. This jack has no metal shell or EMI gasket — it is intended for applications where shielding is handled at the system level or not required.
