RJ45 Jack for Panel-Mount Ethernet — Shielded, Right-Angle, Cat5
The TE Connectivity 5569262-1 is a modular jack with 8 positions and 8 contacts (8P8C), wired for RJ45 Ethernet. It sits in the 5569262 series as a right-angle, through-hole solder version, shielded with an EMI finger to suppress radiated emissions in industrial or telecom enclosures.
Shielding and Orientation — Board Layout Fit
Rated Cat5, this jack handles 100 MHz signals — suited for 10/100BASE-T Ethernet links. The tab direction is up and down — the latch on a standard RJ45 plug engages from either side, so the jack accepts both orientations without a dedicated keying feature.
