TE Connectivity AMPLIMITE series backshell, 5748678-4, 37 positions, 180° cable exit, unshielded, ABS plastic, Black, includes Mating Screws 4-40 and grommets, Bulk.
| Parameter | Value |
|---|---|
| Series | AMPLIMITE |
| Cable type | Round |
| Accessory type | Two Piece Backshell |
| Cable exit | 180° |
| Color | Black |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Primary material | Plastic |
| Package | Bulk |
| Features | Mating Screws 4-40 |
| Hardware | Assembly Hardware, Grommets |
| Shielding | Unshielded |
| Positions | 37 |
| Compatible D-Sub size | 37pos and HD62pos |
| Compatible shell size | C |
The TE Connectivity AMPLIMITE 5748678-4 is a two-piece backshell for 37-position D-subminiature connectors. It accepts round cable with a 180° straight exit and includes the Mating Screws 4-40 and grommets as part of the assembly hardware. The shell is molded from ABS plastic in black and is unshielded, so it provides cable strain relief and connector retention but no EMI containment.
Yes, the backshell includes Mating Screws 4-40 and assembly hardware including grommets as standard.
