26-Position Shielded D-Sub Plug for Ribbon Cable
It carries male pins in a 2-row layout on the series' defining 0.050 inch pitch (0.100 inch row-to-row spacing) — the tightest pitch in TE's standard D-sub family, built for high-density signal interconnects inside equipment racks and panel assemblies. The shielded steel shell with tin-nickel plating contains radiated emissions, making this plug a direct fit for parallel I/O links, industrial controller interfaces, and data-acquisition cabling where signal integrity matters inside a metal enclosure.
The IDC termination style means the 5749621-2 is designed to be mass-terminated to standard 26-conductor ribbon cable without stripping individual wires — the insulation-displacement contacts pierce the ribbon in one press operation. This saves assembly time on multi-conductor runs but requires the correct tooling (a hand press or arbor press with the appropriate die set). The free-hanging (in-line) mounting suits it for cable-to-panel or cable-to-board applications where the plug floats on the harness, not fixed to a PCB.
Ratings and Material Choices for Signal Duty
Rated 1 A per contact and 30 V, the 5749621-2 is a signal-level interconnect — the 1 A limit reflects the dense 0.050 inch pitch and the IDC contact interface, not a power-contact design. Gold-plated phosphor bronze contacts handle repeated mating cycles without surface oxidation, which matters for field-serviceable cable assemblies that get reconnected during maintenance.
