Crimp termination, 14-18 AWG wire range
The 60775-1 is a standard-profile spade terminal from TE Connectivity AMP Connectors, accepting 14-18 AWG wire with a crimp termination for free-hanging in-line installation. The brass contact carries a #10 stud size with a tongue inside opening of 0.197" (5.00mm) and an overall length of 0.798" (20.27mm).
Wire gauge and insulation diameter limits
The terminal accepts wire insulation diameters from 0.100" to 0.140" (2.54mm to 3.56mm) — the non-insulated barrel crimps directly onto the stripped conductor, so the insulation range applies to the wire jacket, not the crimp zone. The base product number 60775 covers the family; the -1 suffix distinguishes this specific stud size and wire gauge combination.
