100-Position Mezzanine Plug for Dense Board Stacking
The SMT tails and integrated board guide simplify alignment during reflow assembly — the guide takes the shear load off the fine-pitch solder joints when the boards are mated.
Stacking Height Options and Mating
The 7.60 mm height above board of the plug itself is fixed; the total stack comes from the paired receptacle height. For a 100-position, 0.80 mm pitch mezzanine link, confirm the receptacle order code matches the target z-height before committing the BOM.
