TE 746611-8 AMP-Latch DIP Header, 14 Pos, 0.100" Pitch

MPN746611-8
Active

TE Connectivity AMP-Latch series, 746611-8, DIP header for ribbon cable IDC termination, 14 positions, 2 rows, 0.100" (2.54mm) board-side pitch, 0.050" (1.27mm) cable pitch, 30.0µin gold contacts, through-hole mounting, black housing.

$3.6600Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

746611-8 Technical Specifications
ParameterValue
SeriesAMP-Latch
Mounting typeThrough Hole
Connector typeRibbon Cable, DIP Header
Wire gauge28 AWG, Stranded; 26-30 AWG, Solid
Cable pitch0.050\" (1.27mm)
Cable terminationIDC
ColorBlack
PackageTray
FeaturesFeed Through
Row spacing0.300\" (7.62mm)
Contact finishGold
Rows2
Board-Side pitch0.100\" (2.54mm)
Positions14
Contact finish thickness30.0µin (0.76µm)

Product details

The 746611-8: The dual-row layout with 0.300-inch (7.62 mm) row spacing matches the standard DIP IC footprint, so the connector plugs directly into a through-hole PCB layout or a DIP socket. The black housing carries a feed-through feature that lets the ribbon cable pass straight through the connector body, keeping the cable routing clean above the board.

Contact Finish and Termination

The IDC termination accepts 28 AWG stranded wire or 26-30 AWG solid wire, which covers the standard range for 0.050-inch pitch ribbon cable. The through-hole mounting tails are tin-plated on the solder side for a reliable wave-solder joint.

The closest functional peer in the AMP-Latch line is the 1-216791-6, a 16-position DIP header with the same 0.100-inch board-side pitch and IDC termination. The decision between them comes down to circuit count: 14 positions on the 746611-8 against 16 on the 1-216791-6.

Frequently asked questions

What wire gauge does 746611-8 support?

The 746611-8 accepts 28 AWG stranded wire and 26-30 AWG solid wire through its IDC termination slots.

Is 746611-8 RoHS compliant?

Yes, the 746611-8 is RoHS3 compliant.
