748364-1 — TE Connectivity AMP Connectors product photo

TE AMPLIMITE HDP-22 748364-1, D-Sub HD Plug Housing, 15 Pos

MPN748364-1
Active

TE Connectivity AMPLIMITE HDP-22 D-Sub High Density Plug Housing, 748364-1, 15 positions, 3 rows, free-hanging, steel shell with tin plating, grounding indents, black PA housing, bulk.

$4.0900Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

748364-1 Technical Specifications
ParameterValue
SeriesAMPLIMITE HDP-22
GenderSignal
Mounting typeFree Hanging (In-Line)
Connector typePlug for Male Contacts
Shell size, connector layout1 (DE, E) High Density
ColorBlack
Dielectric materialPolyamide (PA), Nylon, Glass Filled
Shell material, finishSteel, Tin Plated
NoteContacts Not Included
PackageBulk
FeaturesGrounding Indents
Flange featureHousing/Shell (Unthreaded)
Rows3
Positions15

Product details

The 'high density' designation means the contact spacing is tighter than a standard DE-15 shell – 0.090-inch pitch versus the usual 0.108-inch – so you get more circuits in the same shell footprint.

This is a housing only – no contacts are included. You need to order the AMPLIMITE HDP-22 male crimp terminals (typically part number 1-66506-0 or equivalent) and a suitable insertion/extraction tool. The housing accepts signal-gauge wire; the contact cavity layout matches the standard HDP-22 pin arrangement. Free-hanging (in-line) mounting means no board footprint – the assembly terminates to a cable bundle.

Frequently asked questions

Does 748364-1 include contacts?

No. The 748364-1 is a housing only; contacts are not included and must be ordered separately as AMPLIMITE HDP-22 male crimp terminals.
