796638-9 TE Connectivity 9-Position Right-Angle Header

MPN 796638-9
Active

TE Connectivity AMP Connectors Termi-Blok, Buchanan series, 9-position right-angle shrouded header, 0.200" (5.08mm) pitch, through-hole solder termination, tin-plated contacts, 15 A at 300 V, UL94 V-0.

$3.1200 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
SeriesTermi-Blok, Buchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

796638-9 key specifications
ParameterValue
TypeHeader, Male Pins, Shrouded (4 Side)
SeriesTermi-Blok, Buchanan
MountingThrough Hole
Voltage - UL300 V
Current - UL15 A
Operating temperature-40°C ~ 110°C
ColorGreen
Contact materialCopper Alloy
Housing materialPolyamide (PA66), Nylon 6/6
Insulation height0.329\" (8.36mm)
Material flammability ratingUL94 V-0
Pitch0.200\" (5.08mm)

All specifications

796638-9 additional specifications
ParameterValue
PackageBulk
Number of levels1
Termination styleSolder
Header orientation90°, Right Angle
Contact tail length0.138\" (3.50mm)
Positions9
Positions per level9
Contact mating finishTin

Product details

What this 9-position right-angle header does on the board

The 796638-9 is a 9-position, single-level header from the Termi-Blok, Buchanan series. Rated 15 A at 300 V per UL, with tin-plated copper alloy contacts. The shrouded (4 side) housing protects the pins from accidental shorting during handling.

Pitch, current, and the 5.08 mm footprint

The contact tail length of 0.138" (3.50 mm) is long enough for standard 1.6 mm PCBs with through-hole solder.
