4-Position Buchanan Plug with Rising Cage Clamp
The 796858-4: This 4-position plug from the Buchanan series uses a screw-driven rising cage clamp to terminate solid or stranded wire from 12 to 30 AWG — the clamp lifts inside the housing, pulling the conductor against the current bar without damaging strands.
Screw Torque and Wire Range Fit
The rising cage clamp accepts 0.05-3 mm² wire (12-30 AWG) and the M3 screw is torqued to 0.79 Nm — over-tightening can strip the PA66 threads, under-tightening leaves the conductor loose in vibration. Operating temperature from -40°C to 110°C covers most indoor industrial cabinets and outdoor enclosures where the ambient stays below the derating curve.
