Terminal block header for panel wiring — 3 positions, 5.00 mm pitch
The 796864-3 is a 3-position, single-level, right-angle header from TE Connectivity's Buchanan series. It carries a shrouded (4 side) design with a mating flange, rated 15 A at 300 V per UL. The 5.00 mm pitch is a standard spacing for terminal block connectors used in industrial control, HVAC, and power distribution panels. The contact mating finish is tin, which is suitable for moderate mating cycles in fixed installations.
Right-angle through-hole mounting for board-edge wiring
This is useful in enclosures where vertical space is limited or where the wiring must exit along the board edge. The contact tail length is 0.138" (3.50 mm), which determines the PCB hole depth and solder joint profile.
