TE Connectivity AMP Connectors 796867-4

796867-4 TE Connectivity 4-Position 5.08mm Header, 15A 300V

MPN 796867-4
Active

TE Connectivity AMP Connectors Buchanan series, Header, Male Pins, Shrouded (4 Side), 4 Positions, 0.200" (5.08mm) Pitch, Through Hole, Solder, 15 A, 300 V, Tin Contact Mating Finish, Vertical, Green, Bulk

$6.7200 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

796867-4 key specifications
ParameterValue
TypeHeader, Male Pins, Shrouded (4 Side)
SeriesBuchanan
MountingThrough Hole
Voltage - UL300 V
Current - UL15 A
Operating temperature-40°C ~ 110°C
ColorGreen
Contact materialCopper Alloy
Housing materialPolyamide (PA66), Nylon 6/6
Insulation height0.472\" (12.00mm)
Material flammability ratingUL94 V-0
Pitch0.200\" (5.08mm)

All specifications

796867-4 additional specifications
ParameterValue
PackageBulk
FeaturesMating Flange
Number of levels1
Termination styleSolder
Header orientationVertical
Contact tail length0.138\" (3.50mm)
Positions4
Positions per level4
Contact mating finishTin

Product details

4-position 5.08 mm pitch header for power distribution

The 796867-4 is a 4-position vertical shrouded header from TE's Buchanan series, designed for wire-to-board terminal block applications. Its 0.200" (5.08 mm) pitch sets the PCB footprint and the per-contact current ceiling — at 15 A per contact (UL rated), the temperature rise stays within the PA66 housing limits. The 300 V voltage rating suits industrial control panels, power supplies, and HVAC equipment where a compact, reliable power interface is needed.

With 4 positions on a single level, this header occupies minimal board real estate while delivering 15 A per circuit. The 0.200" pitch allows standard 5.08 mm terminal block spacing — common for screw-clamp or spring-clamp mating connectors.

Mating flange and through-hole termination

Through-hole solder termination (0.138" tail length) offers robust mechanical attachment to the PCB, suitable for environments with moderate vibration.

MPN
796867-4
