9-1740154-6 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE 9-1740154-6 DuoPlug Receptacle, 6 Pos, 0.098" Pitch

MPN9-1740154-6
Active

TE Connectivity DuoPlug receptacle, 6 positions, 0.098" (2.50mm) pitch, 1 row, IDC termination, 22-24 AWG, tin contacts, free-hanging right-angle, blue housing, bulk.

$0.5800Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

9-1740154-6 Technical Specifications
ParameterValue
SeriesDuoPlug
Wire typeDiscrete
GenderFemale Blade Socket
Mounting typeFree Hanging (In-Line), Right Angle
Connector typeReceptacle
Wire gauge22-24 AWG
Cable terminationIDC
ColorBlue
Pitch0.098\" (2.50mm)
PackageBulk
FeaturesBoard Lock, Mates to PCB
Contact finishTin
Rows1
Positions6

Product details

The TE Connectivity 9-1740154-6 is a 6-position DuoPlug receptacle with a 0.098" (2.50mm) pitch, designed for discrete wire IDC termination to 22-24 AWG. The single-row, right-angle, free-hanging body carries tin-plated female blade sockets and integrates a board lock for positive retention to the PCB. The blue housing distinguishes it visually in a harness — useful when multiple DuoPlug connectors share a panel or cable bundle.

IDC termination means the wire insulation is displaced by the contact tines as the cap is pressed home — no stripping, no crimp tool, just a press. The 22-24 AWG range covers common signal and low-power wiring in control cabinets and appliance harnesses.

Board Lock for PCB Retention

Without it, the IDC termination forces alone would rely on the solder joints for mechanical retention — the lock takes that load.

Frequently asked questions

What is the pitch of 9-1740154-6?

The pitch is 0.098" (2.50mm). That dimension sets the footprint on the PCB — the board lock and solder tails align to that spacing.

What wire gauge does 9-1740154-6 accept?

It accepts 22-24 AWG discrete wire. The IDC termination works with solid or stranded within that range — no stripping needed.

Where can I buy 9-1740154-6?

This part is active and quoted to order against your BOM quantity.
