TE Connectivity AMP Connectors T4110401041-000

T4110401041-000 M12 Plug, 4-Pos Female, IP67, B-Coded

MPN T4110401041-000
Active

M12 circular connector, plug, 4-position female sockets, B-coded, IP67, screw termination, 4A, 250V, unshielded, gold-plated contacts, includes backshell and coupling nut, free-hanging.

$7.1100 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesM12
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

T4110401041-000 key specifications
ParameterValue
SeriesM12
MountingFree Hanging (In-Line)
Connector typePlug, Female Sockets
Fastening typeThreaded
Voltage rating250V
Current rating4A
IP ratingIP67 - Dust Tight, Waterproof
Cable opening0.157\" ~ 0.236\" (4.00mm ~ 6.00mm)
Operating temperature-40°C ~ 85°C
ColorBlack, Silver
Shell materialBrass
Insert materialPolyamide (PA), Nylon

All specifications

T4110401041-000 additional specifications
ParameterValue
Contact materialZinc Alloy
Primary materialMetal
Backshell material, platingPolybutylene Terephthalate (PBT), Glass Filled
PackageBulk
FeaturesBackshell, Coupling Nut
ShieldingUnshielded
OrientationB
TerminationScrew
ApplicationsIndustrial
Shell finishNickel
Positions4
Shell size - insertM12-4
Contact finish - matingGold
Contact finish thickness - mating3.00µin (0.076µm)

Product details

The T4110401041-000 is an M12 plug with 4 female sockets, B-coded, terminated via screw terminals. It is designed for free-hanging (in-line) installation in industrial fieldbus and sensor/actuator networks where IP67 sealing is required. The threaded coupling nut provides vibration-resistant mating, and the included backshell handles cable strain relief over a 4.00mm to 6.00mm cable diameter range. Rated 4A per contact at 250V, it carries gold-plated mating surfaces (3.00µin) for corrosion resistance in factory-floor environments.

It is unshielded, so it relies on the overall cable shield or conduit for EMI protection. In a shielded cable assembly, the metal shell (brass with nickel finish) provides some common-mode reference, but the connector itself does not ground the cable braid. For environments with high electrical noise, a shielded M12 variant would be the correct choice.

MPN
T4110401041-000
