T4111411041-000 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE Connectivity T4111411041-000 M12 Receptacle, 4 Pos

MPNT4111411041-000
Active

TE Connectivity M12 receptacle, male pins, 4 positions, B-coded, IP67, shielded, screw termination, 4A, 250V, gold contact finish.

$10.3000Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

T4111411041-000 Technical Specifications
ParameterValue
SeriesM12
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle, Male Pins
Fastening typeThreaded
Voltage rating250V
Current rating4A
Ingress protectionIP67 - Dust Tight, Waterproof
Cable opening0.157\" ~ 0.236\" (4.00mm ~ 6.00mm)
Operating temperature-40°C ~ 85°C
ColorSilver
Shell materialBrass
Insert materialPolyamide (PA), Nylon
Contact materialZinc Alloy
Primary materialMetal
Backshell material, platingBrass, Nickel
PackageBulk
FeaturesBackshell
ShieldingShielded
OrientationB
TerminationScrew
ApplicationsIndustrial
Shell finishNickel
Positions4
Shell size - insertM12-4
Contact finish - matingGold
Contact finish thickness - mating3.00µin (0.076µm)

Product details

M12 B-Coded Receptacle – 4-Position, Shielded, IP67

The T4111411041-000: It is designed for industrial sensor/actuator networks, fieldbus cabling, and any environment where dust-tight, waterproof (IP67) connectivity is required. The B-coding prevents accidental mating with A-coded or D-coded M12 connectors, so the wiring scheme stays correct when the harness is plugged in blind under a panel.

The cable opening range of 0.157" to 0.236" (4.00 mm to 6.00 mm) accepts common sensor cables; the screw termination gives a secure, tool-friendly wire fix. The brass shell with nickel finish and integrated backshell provides 360° shielding, which is essential for keeping EMI out of signal lines in a VFD-filled cabinet.

Frequently asked questions

Is T4111411041-000 A-coded or B-coded?

It is B-coded. The B-coded keying prevents mating with A-coded or D-coded M12 connectors, ensuring correct wiring in fieldbus or sensor networks.

What is the cable opening range for T4111411041-000?

The backshell accepts cables with an outer diameter of 0.157" to 0.236" (4.00 mm to 6.00 mm).

Where can I buy T4111411041-000 and what is the price?

This part is active and sourced to order.
