The TE Connectivity T4113012051-000 is an M12 A-coded receptacle with male pins, designed for industrial sensor/actuator and fieldbus networks where a threaded, vibration-proof connection and IP67 sealing are required. It carries 5 positions rated 4A per contact at 60V, with gold-plated mating surfaces (3.00 µin) on zinc alloy contacts. The nickel-plated brass shell provides shielding, and the right-angle free-hanging form factor with a screw-termination backshell suits cable routing in tight enclosures or along machine frames. The cable opening range is 0.236" to 0.315" (6.00mm to 8.00mm).
IP67 only when mated — cap the open half
If the receptacle sits unmated on a panel or cable drop, the open face is not sealed; a protective cap is needed to maintain the IP rating between connections. The housing uses a polyamide (nylon) insert; the gasket seal is part of the mating interface, not a separate O-ring on the receptacle itself.
Mating half and pinout
This receptacle mates with a standard M12 A-coded male connector (male plug with female contacts). The A-coding orientation ensures correct pin alignment — a B-coded or D-coded plug will not mate. The 5-position pinout follows the M12-5 A-coded assignment: typically pin 1 = brown (+), pin 2 = white, pin 3 = blue (-), pin 4 = black, pin 5 = grey (shield or signal). Confirm the specific device wiring diagram for your application.
