TE Connectivity AMP Connectors T4131012081-000

TE Connectivity T4131012081-000 M12 Receptacle, 8-Pin, IP67

MPN T4131012081-000
Active

TE Connectivity M12 A-coded receptacle, 8-position female sockets, solder cup, panel mount, IP67, 2 A, 30 V, nickel shell, gold mating contacts.

$13.9700 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
SeriesM12
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

T4131012081-000 key specifications
ParameterValue
SeriesM12
MountingPanel Mount
Connector typeReceptacle, Female Sockets
Fastening typeThreaded
Voltage rating30V
Current rating2A
IP ratingIP67 - Dust Tight, Waterproof
Mounting featureBulkhead - Front Side Nut
Operating temperature-40°C ~ 85°C
ColorSilver
Shell materialCopper Alloy
Insert materialPolyamide (PA66), Nylon 6/6

All specifications

T4131012081-000 additional specifications
ParameterValue
Contact materialCopper Alloy
Primary materialMetal
PackageBulk
ShieldingUnshielded
OrientationA
TerminationSolder Cup
ApplicationsIndustrial
Shell finishNickel
Positions8
Shell size - insertM12-8
Contact finish - matingGold

Product details

What This M12 Receptacle Does in a Panel or Harness

The T4131012081-000: It terminates via solder cup — no crimp tool needed for field wiring — and mates with any standard M12 A-coded 8-position male plug. The nickel-plated copper alloy shell and gold mating contacts suit industrial sensor, actuator, and fieldbus connections where the connector sees occasional mate-unmate cycles in a washdown or dusty environment.

IP67 Sealing and the Operating Envelope

The seal holds when mated with the corresponding IP67-rated plug; the panel gasket sits behind the bulkhead nut.

2 A at 30 V — Signal-Level Current, Not Power

The 8-position count and A-coding are common for DeviceNet, CANopen, and some Ethernet-over-M12 pinouts. If your application needs to pass more than 2 A per pin or higher voltage, step up to an M12 power variant (L- or S-coded) with thicker contacts. The gold mating finish supports the rated cycle life without contact fretting in low-current signal paths.

Solder Cup Termination and Panel Mounting

Termination is solder cup — strip, tin, and solder each wire into the cup. This is the standard field-termination method for M12 receptacles; no special crimp die or tooling is required, which matters for maintenance spares and low-volume builds. The bulkhead-front-side-nut mounting secures the receptacle from the panel face, with the threaded coupling ring accessible on the mating side.

MPN
T4131012081-000
