T4131412041-000 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE Connectivity T4131412041-000 M12 Plug, 4-Pin, B-Coded

MPNT4131412041-000
Active

TE Connectivity M12 plug, female sockets, 4 positions, B-coded, solder cup termination, panel mount, IP67, 4A, 250V, nickel shell, unshielded.

$7.2400Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

T4131412041-000 Technical Specifications
ParameterValue
SeriesM12
Mounting typePanel Mount
Connector typePlug, Female Sockets
Fastening typeThreaded
Voltage rating250V
Current rating4A
Ingress protectionIP67 - Dust Tight, Waterproof
Mounting featureBulkhead - Front Side Nut
Operating temperature-30°C ~ 85°C
ColorSilver
Shell materialCopper Alloy
Insert materialPolyamide (PA66), Nylon 6/6
Contact materialCopper Alloy
Primary materialMetal
Material flammability ratingUL94 V-0
PackageBulk
ShieldingUnshielded
OrientationB
TerminationSolder Cup
ApplicationsIndustrial
Shell finishNickel
Positions4
Shell size - insertM12-4
Contact finish - matingGold
Contact finish thickness - mating3.00µin (0.076µm)

Product details

M12 B-Coded Field-Wireable Plug for Industrial I/O

The T4131412041-000: It is designed for panel-mount applications using a bulkhead front-side nut, with a threaded coupling for vibration-resistant mating.

Solder Cup Termination — Field Flexibility

The solder cup termination allows the installer to terminate individual wires without a crimp tool — useful for on-site repairs, custom cable lengths, or low-volume builds. The gold-plated mating contacts with 3.00µin thickness provide reliable contact for moderate mating cycles.

Frequently asked questions

Is T4131412041-000 shielded or unshielded?

The T4131412041-000 is unshielded. The metal shell provides some mechanical protection but no dedicated EMI shielding. For electrically noisy environments, use a shielded cable and a shielded M12 connector variant, or ensure the enclosure provides adequate screening.
