Panel-Mount M12 Receptacle, 3-Pin Male, B-Coded
The T4132412031-000 is a 3-position M12 receptacle with male pins, B-coded, designed for panel-mount industrial applications. It terminates via solder cup and secures with a threaded coupling nut, delivering an IP67-rated seal when mated with the corresponding female cordset. The nickel-plated copper alloy shell and gold-plated contacts (3.00 µin) suit environments where corrosion resistance and reliable signal or low-power connections are needed.
Rated for 4A at 250V with IP67 Seal
Rated 4A per contact at 250V, this M12 receptacle handles sensor, actuator, and low-power signal circuits in factory automation and process control panels. The IP67 rating means the mated pair resists dust ingress and temporary water immersion — suited for washdown zones, conveyor lines, and outdoor cabinet interfaces. The B-coding prevents cross-mating with A- or D-coded M12 connectors, keeping the wiring scheme intact.
Mounts in a Bulkhead Cutout, Secured with a Rear Nut
The bulkhead - rear side nut mounting feature lets you drop the receptacle through a panel cutout and tighten the nut from the back side. The threaded coupling ring on the mating half provides a vibration-resistant lock — important for equipment subject to machine vibration or cable strain. Solder cup termination means you tin the wire, insert into the cup, and solder; no crimp tool required, but allow for heat-shrink or boot over the joint if the environment is wet.
