M12-4 Panel-Mount Receptacle, Male Pins, IP67 Sealed
The T4132512041-000: It uses the standard M12-4 shell size and a D-coded orientation, with threaded fastening for a vibration-resistant mate.
4 A per Contact, 250 V — Signal-Level Power for Sensor Networks
The solder cup termination allows field wiring without a crimp tool, though the wire gauge must be matched to the cup size for reliable solder joints.
IP67 Sealing and Temperature Range
The bulkhead mounting feature with rear-side nut allows the receptacle to be fixed to a panel, with the threaded coupling ring on the mating cable connector providing the seal compression. The O-ring seal is on the mating interface, not the panel face — ensure the panel cutout is clean and burr-free to maintain the seal.
The threaded coupling ensures a secure, vibration-resistant connection. The D-coded orientation provides keying to prevent mis-mating with A-coded or B-coded connectors — confirm your cable assembly uses the same D-coding. The solder cup termination accepts field wiring; no crimp tool is required. For best reliability, use a soldering iron with temperature control and a heat-shrink tube over the solder joint to protect against strain and moisture ingress.
