T4133412031-000 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE T4133412031-000 M12 B-Coded 3-Pin Female Plug, IP67

MPNT4133412031-000
Active

TE Connectivity M12 B-coded plug, 3-position female, solder cup termination, panel mount with rear side nut, IP67, 4 A, 250 V, gold-plated contacts, UL94 V-0.

$6.4500Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

T4133412031-000 Technical Specifications
ParameterValue
SeriesM12
Mounting typePanel Mount
Connector typePlug, Female Sockets
Fastening typeThreaded
Voltage rating250V
Current rating4A
Ingress protectionIP67 - Dust Tight, Waterproof
Mounting featureBulkhead - Rear Side Nut
Operating temperature-40°C ~ 85°C
ColorSilver
Shell materialCopper Alloy
Insert materialPolyamide (PA66), Nylon 6/6
Contact materialCopper Alloy
Primary materialMetal
Material flammability ratingUL94 V-0
PackageBulk
ShieldingUnshielded
OrientationB
TerminationSolder Cup
ApplicationsIndustrial
Shell finishNickel
Positions3
Shell size - insertM12-3
Contact finish - matingGold
Contact finish thickness - mating3.00µin (0.076µm)

Product details

Panel-Mount M12 B-Coded Female Plug for Industrial Field Wiring

The B-coded orientation is specific to fieldbus and industrial Ethernet applications — an A-coded receptacle will not mate, so confirm the coding on the mating cordset before committing the BOM line. The metal shell (copper alloy with nickel finish) and polyamide PA66 insert carry an IP67 rating when mated, meaning the interface seals against dust immersion and temporary water submersion, suited for washdown zones on packaging lines or machine-tool enclosures.

Wiring and Termination — Solder Cup Field Install

Termination is solder cup — each of the three contacts is soldered directly to the conductor.

Frequently asked questions

What is T4133412031-000 compatible with?

This is a B-coded M12 female plug — it mates only with a B-coded M12 receptacle or cordset of the same shell size (M12-3). The B orientation is specific to fieldbus and industrial Ethernet networks; an A-coded or D-coded counterpart will not engage.

Is T4133412031-000 RoHS compliant?

Yes, the listing confirms ROHS3 compliance.
