T4140012051-000 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE Connectivity T4140012051-000 M12 5-Pin Male Receptacle

MPNT4140012051-000
Active

TE Connectivity M12 A-coded receptacle, 5 male pins, gold-plated contacts, 4A at 60V, IP67, panel mount, threaded coupling, solder termination.

$7.8400Ref. price · indicative, final on quote
T4140012051-000 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

T4140012051-000 Technical Specifications
ParameterValue
SeriesM12
Mounting typePanel Mount, Through Hole
Connector typeReceptacle, Male Pins
Fastening typeThreaded
Voltage rating60V
Current rating4A
Ingress protectionIP67 - Dust Tight, Waterproof
Mounting featureBulkhead - Front Side Nut
Operating temperature-40°C ~ 85°C
ColorSilver
Shell materialCopper Alloy
Insert materialPolyamide (PA66), Nylon 6/6
Contact materialCopper Alloy
Primary materialMetal
Material flammability ratingUL94 V-0
PackageBulk
ShieldingUnshielded
OrientationA
TerminationSolder
ApplicationsIndustrial
Shell finishNickel
Positions5
Shell size - insertM12-5
Contact finish - matingGold
Contact finish thickness - mating3.00µin (0.076µm)

Product details

M12 A-Coded Male Receptacle — Panel-Mount with IP67 Seal

The T4140012051-000: The nickel-plated copper alloy shell and gold-over-nickel mating contacts (3.00 µin gold) handle repeated mating cycles in industrial environments. Without the mating half engaged, the open receptacle is not sealed.

Current and Voltage — What 4 A at 60 V Means in Practice

Rated 4 A per contact at 60 V, this M12 receptacle is typical for powering sensors, actuators, and fieldbus nodes in industrial control cabinets.

Mating and Termination — Threaded Coupling, Solder Terminals

This receptacle uses a threaded fastening system and mates with any A-coded M12 male plug with a female-threaded coupling ring.

Listed as Active in production.

Frequently asked questions

Does T4140012051-000 have an IP rating?

Yes, it carries an IP67 rating — dust-tight and protected against temporary immersion in water. The rating applies only when the connector is fully mated with the threaded coupling engaged and the panel nut torqued. An unmated receptacle is not sealed.
