Sealed M12 Female Plug for Industrial Panel Wiring
The TE T4145415021-001 is a 2-position M12 female plug, B-coded, with gold-plated contacts and a threaded coupling nut. It is designed for sealed panel-mount applications where the connector must withstand washdown and dust — the IP67 rating applies when mated to a matching M12 cordset, with the O-ring sealing at the bulkhead face.
Mounting and Sealing — What the IP67 Rating Requires
The nickel-plated copper alloy shell and the PA66 insert provide corrosion resistance in humid or washdown environments. A bulkhead mounting feature allows the connector to be panel-mounted, with the O-ring sealing against the cutout. When unmated, the open half should be capped to maintain the seal integrity. The right-angle orientation keeps the cable exit close to the PCB, which matters in shallow enclosures.
