TE Connectivity Deutsch Connectors 0409-201-1800

TE Deutsch HD30 Cable Clamp 0409-201-1800, 1 3/16-18 UNEF

MPN 0409-201-1800
Active

TE Connectivity Deutsch HD30 series cable clamp, shell size 18, 1 3/16-18 UNEF thread, 0.760" cable opening, tin-plated, silver, includes bushing and clamp screws, 180° cable exit, unshielded.

$14.7700 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026

Specifications

0409-201-1800 specifications
ParameterValue
TypeCable Clamp
SeriesHD30
Cable exit180°
Cable opening0.760\" (19.30mm)
ColorSilver
PackageBox
PlatingTin
FeaturesBushing, Clamp Screws
ShieldingUnshielded
Connector size1 3/16-18 UNEF
Diameter - outside1.469\" (37.31mm)
Shell size - insert18
For use with (Related products)HD30 Series Connectors

Product details

What This Clamp Fits and What It Carries

The TE Connectivity Deutsch 0409-201-1800 is a tin-plated, silver cable clamp from the HD30 series, shell size 18. It's the piece that cinches down on the cable jacket at the back of a Deutsch HD30 connector, taking the strain off the contacts and sealing the cable entry. The 1 3/16-18 UNEF thread mates with the matching backshell or connector body, and the 0.760" (19.30 mm) cable opening handles a specific cable diameter range — measure your cable jacket before ordering, because if it's too fat or too skinny the clamp won't seat properly. It ships with the bushing and clamp screws included, so you're not hunting for hardware mid-install. The 180° cable exit means the cable runs straight out the back — no right-angle routing. Unshielded, so it's a mechanical strain relief, not a grounding clamp.

Thread and Cable Fit — What to Check Before You Order

The thread is 1 3/16-18 UNEF — that's a UNEF (Unified Extra Fine) thread, not a standard UNF or UNC. If your mating backshell or connector body has a different thread pitch, this clamp won't thread on. The cable opening is 0.760" (19.30 mm), and the outside diameter of the clamp body is 1.469" (37.31 mm) — that outside diameter matters if you're routing through a tight panel cutout or boot.
