Tensility International Corp 50-00617
MPN50-00617
Active
CONN JACK 2.5MM MOLD STYLE
$2.1900Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Connector type | Jack |
| Voltage - rated | 48VDC |
| Current rating | 7.5 A |
| Operating temperature | -25°C ~ 105°C |
| Body color | Silver |
| Body material | Brass |
| Contact material | Brass |
| Contact material - plating | Nickel |
| Material flammability rating | UL94 V-0 |
| Gender | Male |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Features | Thread Lock |
| Shielding | Unshielded |
| Termination | Solder Cup, Solder Eyelet |
| Connector size | 5/16\"-32 |
| Actual diameter | 0.098\" (2.50mm ID), 0.222\" (5.65mm OD) |
| Internal switch | Does Not Contain Switch |
| Number of positions (Contacts) | 2 Conductors, 2 Contacts |
| Industry recognized mating diameter | 2.50mm ID (0.098\"), 5.50mm OD (0.217\") |
