20021111-00010T1LF — Amphenol product photo
Amphenol

20021111-00010T1LF Amphenol ICC Minitek127 1.27mm Header

MPN20021111-00010T1LF
Active

Amphenol ICC (FCI) Minitek127® 1.27mm unshrouded header, 10 positions, 2 rows, through hole, gold flash on mating contacts, tin on posts, rated 1 A per contact at 125 VAC, UL94 V-0, -55°C to 125°C.

$0.7900Ref. price · indicative, final on quote
20021111-00010T1LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

20021111-00010T1LF Technical Specifications
ParameterValue
SeriesMinitek127® 1.27mm
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating125VAC
Current rating1A per Contact
Operating temperature-55°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.098\" (2.50mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.050\" (1.27mm)
Positions10
Row spacing - mating0.050\" (1.27mm)
Contact finish - postTin
Contact length - post0.091\" (2.30mm)
Overall contact length0.309\" (7.86mm)
Contact finish - matingGold
Contact length - mating0.120\" (3.05mm)
Contact finish thickness - post50.0µin (1.27µm)
Contact finish thickness - matingFlash

Product details

Board-to-Board Fit and Mating Half

The 20021111-00010T1LF: This is a 10-position, 2-row unshrouded header on 1.27 mm pitch — the same footprint used by standard 1.27 mm IDC socket connectors and Minitek127 receptacles. For higher cycle counts, the 20021111-00010T4LF sibling carries 10 µinch gold on the mating contact.

Comparing the Gold Flash vs Thicker Gold Variant

The 20021111-00010T4LF is the same 10-position, 1.27 mm pitch header but with 10 µinch gold on the mating contact instead of flash.

Frequently asked questions

Is 20021111-00010T1LF pin compatible with standard 1.27 mm IDC connectors?

Yes — the 1.27 mm pitch, 2-row layout, and unshrouded design mate directly with standard 1.27 mm IDC socket connectors and Minitek127 receptacles. Confirm the mating half has a 0.120" (3.05 mm) pin entry depth.
