1.27mm Pitch, 6-Position Dual-Row SMT Header
The 20021121-00006C4LF: This is a 6-position, dual-row unshrouded header from the Minitek127® 1.27mm series, terminated by SMT solder. The UL94 V-0 thermoplastic housing holds up in equipment requiring flame-rated materials inside an enclosure.
It's RoHS compliant.
Board-to-Board Fit and Mating
The 0.120" (3.05mm) mating pin length engages the receptacle contact beam. Dual-row spacing at 1.27mm matches the pitch, keeping the board-to-board stack height predictable. Pick-and-place compatible packaging (Tape & Reel, Cut Tape) suits automated assembly lines. The square male pins and copper alloy contact material handle the mechanical insertion force without deformation.
Peer Comparison: 6 vs 10 Positions
Compared to the 10-position sibling 20021121-00010C4LF, this 6-position version shares the same 1.27mm pitch, gold mating finish, and SMT termination. The difference is circuit count — 6 positions vs 10 — which affects the board footprint width and the number of signal lines. Both are active and RoHS compliant.
