20021612-00012T4LF Amphenol ICC Minitek127 1.27mm

MPN20021612-00012T4LF
Active

Amphenol ICC (FCI) Minitek127® 20021612 series, 12-position dual-row header, 1.27mm pitch, right-angle through-hole, shrouded 4-wall with latch lock, gold-plated male pins, 1A per contact, 125VAC.

$3.0800Ref. price · indicative, final on quote
20021612-00012T4LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

20021612-00012T4LF Technical Specifications
ParameterValue
SeriesMinitek127® 20021612
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typeLatch Lock/Eject Hooks
Voltage rating125VAC
Current rating1A per Contact
Operating temperature-40°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.220\" (5.60mm)
Insulation materialPlastic
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.050\" (1.27mm)
Positions12
Row spacing - mating0.050\" (1.27mm)
Contact length - post0.091\" (2.30mm)
Contact finish - matingGold
Contact finish thickness - mating10.0µin (0.25µm)

Product details

Board Layout and Pitch Check

The 20021612-00012T4LF: This is a 12-position, dual-row header on 0.050" (1.27mm) pitch — the same pitch used by standard 1.27mm IDC ribbon cable assemblies. The row spacing is also 0.050" (1.27mm), so the footprint is a 6x2 grid of 0.025" square pins. The post length is 0.091" (2.30mm) — enough for a standard 1.6mm PCB with a through-hole solder joint.

The keying slot ensures the cable plug can only go in one way, which avoids pin damage on assembly. The insulation height is 0.220" (5.60mm), so plan for that clearance above the board when routing the cable.

Current and Temperature Limits

The UL94 V-0 plastic housing keeps the connector safe inside equipment enclosures that require flame-rated materials.
