54101-G0830LF — Amphenol product photo
Amphenol

54101-G0830LF Amphenol ICC BERGSTIK Header, 30 Pos, 2.54mm

MPN54101-G0830LF
Active

Amphenol ICC (FCI) BERGSTIK® header, order code 54101-G0830LF, 30 positions, single row, 0.100" (2.54mm) pitch, 3A per contact, gold or GXT™ mating finish, through-hole, solder termination.

$2.6307Ref. price · indicative, final on quote
54101-G0830LF datasheet
StockIn Stock (25)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54101-G0830LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions30
Contact finish - postTin
Contact length - post0.120\" (3.05mm)
Overall contact length0.450\" (11.43mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

BERGSTIK unshrouded header, 30 positions

The 54101-G0830LF is the 30-position single-row member of Amphenol ICC's BERGSTIK unshrouded header line. It carries gold or GXT™ mating contacts rated 3A per contact at 0.100" pitch and terminates through-hole with solder.

Series and position selection

Within the BERGSTIK series the 54101-G0830LF's 30 positions are the highest single-row count — the 0.100" pitch, unshrouded push-pull interface, and through-hole termination are shared across the series, so match the position count to circuit count.
