Amphenol ICC (FCI) BERGSTIK series, 54102-G0507LF, 14-position dual-row unshrouded header, 0.100" (2.54mm) pitch, through-hole solder termination, male pin contacts, gold or GXT mating finish (30.0 µinch), 3 A per contact, UL94 V-0, -65 to 125 °C.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 54102-G0507LF: Dual-row layout means the 14 positions occupy a 2x7 pattern, not a single row. The 0.425" (10.80mm) overall contact length keeps the mated stack height at a typical 0.230" (5.84mm) above the board.
Supplied by Amphenol ICC (FCI) under the BERGSTIK series.
Termination is solder only — no press-fit option. The tin-plated post (100.0 µinch) accepts solder well but does not support solderless press-fit assembly.
This part is sourced per RFQ through independent distribution.
0.100" (2.54mm) pitch, 14 positions arranged in two rows of 7. All positions are loaded.
