54102-G0800LF — Amphenol product photo
Amphenol

54102-G0800LF BERGSTIK Header – 0.100" Pitch, Cuttable Strip

MPN54102-G0800LF
Active

Amphenol FCI BERGSTIK 54102-G0800LF, unshrouded dual-row pin header, 0.100" (2.54mm) pitch, 45000 positions cuttable strip, gold or Gold GXT on mating side / tin solder tails, 3A per contact, -65 to 125°C operating, phosphor bronze contacts, UL94 V-0, push-pull fastening, through-hole.

$0.7400Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54102-G0800LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions45000, Cuttable
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.120\" (3.05mm)
Overall contact length0.450\" (11.43mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Cuttable strip for flexible BOM fit

The 54102-G0800LF: This BERGSTIK header ships as a 45000-position strip that you cut to the exact circuit count your board needs — no wasted pins, no special-order fixed lengths. The unshrouded dual-row layout with 0.100" (2.54mm) pitch mates with standard IDC receptacles or board-to-board sockets, making it a drop-in for common 0.100"-center designs.

3A rating with wide thermal margin

Rated 3A per contact across a -65°C to 125°C operating range, this header handles signal-level current in industrial cabinets, telecom gear, or outdoor enclosures without derating concerns at typical ambient temperatures.

Frequently asked questions

What does the 54102-G0800LF mate with?

As a dual-row 0.100" pitch unshrouded pin header, it mates with any standard IDC receptacle, dual-row housing, or matching pin-header socket in the same pitch and row spacing.
