Amphenol ICC (FCI) BERGSTIK® header, order code 54102-S06-10-B02LF, 20 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, gold or GXT™ mating finish, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Overall contact length | 0.440\" (11.18mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 54102-S06-10-B02LF is the 20-position member of the BERGSTIK header line, unshrouded, dual-row, with 9 positions loaded.
The 54102-S06-10-B02LF carries 20 positions on a dual-row 0.100" pitch, but only 9 positions are loaded — the remaining 11 positions are unpopulated. This allows the same footprint to serve lower-circuit-count designs without a custom part.
No pin-compatible alternative is listed in the same series. The 54102-S06-10-B02LF has a unique loaded position count (9 of 20) — verify the exact pinout against the mating half before substitution.
