Amphenol ICC (FCI) BERGSTIK® unshrouded header, 20 positions, dual-row, 0.100" (2.54mm) pitch, through-hole solder termination, 3A per contact, 15µin gold on mating face, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.538\" (13.67mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 54102-S3010LF: The post tails are tin-plated (100.0µin) for reliable solder wetting. Operating temperature spans -65°C to 125°C, which covers automotive underhood, outdoor telecom cabinets, and industrial enclosures without needing a derating curve for ambient extremes.
Availability and current pricing confirmed at quote time.
All positions are loaded.
The part number suffix 'LF' indicates lead-free / RoHS-compliant termination finish. Confirm full RoHS status in the manufacturer documentation.
