54102-T30-07 — Amphenol product photo
Amphenol

54102-T30-07 BERGSTIK® Header – 14 Pos, 0.100" Pitch, Tin

MPN54102-T30-07
Active

Amphenol ICC (FCI) BERGSTIK® 54102-T30-07, unshrouded through-hole header, 14 positions, 2 rows, 0.100" (2.54 mm) pitch, tin-plated male pins, rated 3 A per contact, UL94 V-0 black housing.

$0.6500Ref. price · indicative, final on quote
54102-T30-07 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54102-T30-07 Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A per Contact
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions14
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Overall contact length0.538\" (13.67mm)
Contact finish - matingTin
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

Board Fit and Current Ceiling

The 54102-T30-07: In a prototype or low-cycle production run, this plating grade keeps cost down without sacrificing contact resistance.

Unshrouded Push-Pull — What It Mates With

No keying or polarization — the unshrouded design relies on the mating housing for orientation. In a harness build, verify the socket's polarization ribs align with the header's pin rows before committing the BOM.

Choosing Between 14 and 16 Positions

The closest sibling in the same BERGSTIK® series is 54102-T08-08 — identical 0.100" pitch, tin plating, and unshrouded layout, but with 16 positions instead of 14. If the BOM calls for 16 circuits, that part is the direct drop-in; for 14 circuits, this 54102-T30-07 is the correct fit. For applications requiring higher mating cycle life, the 54102-S3005LF carries gold or GXT™ plating (15.0 µinch) on the mating face — a meaningful upgrade for field-service or corrosive environments, though it ships in bulk rather than bag.

Frequently asked questions

Is 54102-T30-07 RoHS compliant?

No — the manufacturer lists this part as RoHS non-compliant. Verify your project's environmental requirements before ordering.

What is the closest functional second-source for 54102-T30-07?

The closest BERGSTIK® sibling is 54102-T08-08 — same 0.100" pitch, tin plating, and unshrouded design, but with 16 positions instead of 14. For a gold-plated alternative, consider 54102-S3005LF (10 positions, 15.0 µinch gold).
