54201-T3017LF — Amphenol product photo
Amphenol

54201-T3017LF Amphenol ICC (FCI) BERGSTIK Header, 17 pos

MPN54201-T3017LF
Active

Amphenol ICC (FCI) BERGSTIK header, order code 54201-T3017LF, 17 positions, single row, 0.100" (2.54 mm) pitch, unshrouded, tin-plated mating contacts, surface-mount, solder termination.

$1.6347Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54201-T3017LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions17
Contact finish - postTin
Contact finish - matingTin
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

Unshrouded single-row header, 17 positions

The 54201-T3017LF: Tin-plated mating contacts and tin-plated posts suit signal-level interconnects where repeated mating cycles stay moderate; the black UL94 V-0 housing mates with matching BERGSTIK receptacles.
