54202-G3005ALF — Amphenol product photo
Amphenol

54202-G3005ALF Amphenol ICC BERGSTIK® Header 10 Pos 2.54mm

MPN54202-G3005ALF
Active

Amphenol ICC (FCI) BERGSTIK® 54202-G3005ALF, unshrouded pin header, 10 circuits, 2 rows, 0.100" (2.54mm) pitch, surface mount, 3 A per contact, 30 µinch gold mating finish, UL94 V-0 black housing.

$0.9200Ref. price · indicative, final on quote
54202-G3005ALF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54202-G3005ALF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesPick and Place
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions10
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

10-Pin, 2.54 mm Pitch, SMT — What This Header Does

The 54202-G3005ALF: Surface-mount termination with a pick-and-place feature means it runs through a standard reflow oven alongside other SMD components.

Peer Comparison: 54202-S0804CLF vs 54202-G3005ALF

The closest functional sibling is 54202-S0804CLF — same series, same pitch, same 3 A rating, same gold mating finish (15 µinch vs 30 µinch on this part). The difference is circuit count: 8 positions vs 10. If the BOM calls for 10 circuits, this is the direct match.

Frequently asked questions

Is 54202-G3005ALF RoHS compliant?

Yes, RoHS compliant per the manufacturer listing.

What is the pitch of 54202-G3005ALF?

0.100" (2.54 mm) on both the mating pitch and the row spacing.

What is the closest functional second-source for 54202-G3005ALF?

The closest peer is 54202-S0804CLF — same series, same pitch, same 3 A rating, but 8 positions instead of 10. If 10 positions are required, this part is the direct match.
