54202-S0806ALF Amphenol ICC BERGSTIK® Header SMD 12POS

MPN54202-S0806ALF
Active

Amphenol ICC (FCI) BERGSTIK® header, 54202-S0806ALF, unshrouded dual-row SMT, 12 positions loaded, 0.100" (2.54mm) pitch, 3 A, 15 µin gold mating finish, UL94 V-0 black housing.

$1.7200Ref. price · indicative, final on quote
54202-S0806ALF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54202-S0806ALF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesPick and Place
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions12
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board Layout Fit: 0.100" Pitch, Dual-Row SMT

The 54202-S0806ALF: The 0.230" (5.84mm) mating pin length gives enough engagement depth for most low-profile receptacles.

Comparing to 8-Position Siblings

The 12-position 54202-S0806ALF shares the same footprint, pitch, plating, and current rating as the 8-position 54202-S0804CLF and 54202-S0804ALF — the only difference is circuit count. If the BOM calls for 8 positions, those siblings drop in without a board layout change; if you need 14 positions, the 54202-S0807LF (bagged, same specs) extends the row length.

Frequently asked questions

Where can I buy 54202-S0806ALF and how is it quoted?

Submit an RFQ for a firm quote.

What is the closest alternative to 54202-S0806ALF with fewer positions?

The 8-position 54202-S0804CLF and 54202-S0804ALF share the same pitch, plating, and SMT footprint — they are drop-in replacements if the BOM only needs 8 circuits.
