54202-T6010TLF — Amphenol product photo
Amphenol

54202-T6010TLF BERGSTIK Header, 20 Pos, 0.100" Pitch, SMT

MPN54202-T6010TLF
Active

Amphenol BERGSTIK® header, order code 54202-T6010TLF, 20 positions, dual row, 0.100" (2.54 mm) pitch, 3 A, tin-plated mating contacts, surface-mount, solder termination.

$0.4559Ref. price · indicative, final on quote
54202-T6010TLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

54202-T6010TLF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions20
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact finish - matingTin
Contact length - mating0.575\" (14.61mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

20-position unshrouded SMT header

The 54202-T6010TLF is the 20-circuit member of the BERGSTIK® unshrouded header line, dual-row, 0.100" pitch. Tin-plated mating contacts rated 3 A, surface-mount termination, push-pull fastening.

Position count across the series

The 20-position 54202-T6010TLF sits between the 10-position and 30-position dual-row siblings in the BERGSTIK® family — the 0.100" pitch, row spacing, and unshrouded profile are shared across the series, so match the position count to circuit count.

Frequently asked questions

What is 54202-T6010TLF's listed style and series?

The style is Board to Board; the series is BERGSTIK®.
