20-Pin SMT Receptacle in the Minitek 2.00mm Family
Surface-Mount Termination and Board Fit
Surface-mount solder tails with tin post finish — the 0.091" (2.30mm) insulation height leaves clearance under the body for trace routing on the top layer.
Amphenol ICC (FCI) Minitek® 2.00mm series, 55508-020LF, board-to-board receptacle, 20 positions, 2 rows, 0.079" (2.00mm) pitch, surface mount, gold mating contacts, 2A rating, UL94 V-0, -55°C~125°C.
$1.6455Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Gender | Female Socket |
| Mounting type | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 200V |
| Current rating | 2A |
| Operating temperature | -55°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.091\" (2.30mm) |
| Insulation material | Plastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tube |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - mating | 1.97µin (0.050µm) |
Product details
Frequently asked questions
What is the mating connector for 55508-020LF?
As a Minitek 2.00mm board-to-board receptacle, it mates with a matching 2.00mm pitch pin header from the same series. The header must be dual-row, 20 positions, with 0.079" row spacing. Confirm the header's mating pin length and stack height against your board-to-board spacing before ordering.
Where can I buy 55508-020LF?
Sourced to order against your BOM quantity. Availability and current pricing confirmed at quote time — submit an RFQ for this part number.
